Features



  • Designed to generate unattenuated point wise target response along range line.
  • The responses provide accurate and yet reliable control points for purpose of radiometric calibration of RADAR
  • The system is flexible, light weight, easy to operate and cost effective.
  • Highly stable RCS by the temperature control of the ARC system
  • Monitoring and analyzing the SAR signal by using the Digital Receiver
  • Polarimetric ARC functionality
  • Specification

    Center frequency 9.7GHz
    Sweep bandwidth 16.6 GHz
    Sampling rate up to 92 GSa/s
    Analog bandwidth 32 GHz (max.)
    Polarization Dual /Quad
    Antenna gain > 20 dBi
    Transmit power > 50 W
    Power Supply 28 Vdc / 400 W
